Stickers Material Product
Orange Peel Tin Foil Adhesive Material

Orange Peel Tin Foil Adhesive Material

Orange peel pattern tin foil adhesive material is a composite material that combines metal tin foil with a high-strength adhesive layer. Its surface is designed with a unique checkered embossing process, featuring both excellent physical properties and practical functions. The products are widely used in fields such as electronic shielding, building waterproofing, industrial sealing, and heat insulation protection, and are renowned for their high adhesion, weather resistance, and electromagnetic shielding properties.

Stickers Key Attributes

Goods Name
Orange Peel Tin Foil Adhesive Material

Surface Substrate

Material Name
Foil
Color
Orange Peel
Thickness
ISO534 160±3 μm
Gram Weight
ISO536 145±3 g/m2

Stickers Adhesive

Adhesive Type
Acrylic
Dry Coating Weight(g/m²)
ISO536 21±5 gsm
Thickness
ISO534 19±5 μm

Release Paper

Material Name
High Quality White Release Paper
Release Force(g/in)
FTM3 10-20g
Color
White
Gram Weight
ISO536 138±3 g/m2
Thickness
ISO534 135±5 μm

Package Size

Dimensions Standard Width
Valid Width:1070mm,Slitting Minimum Width:25mm
Dimensions Standard Length
400M 800M 1000M 2000M
Core Size
Diameter 75mm* Width 1070mm
Joint
2000M ≤1

About Stickers Goods Packing

Storage Temperature
-10℃-40℃
Storage
Keep indoor,airiness,avoiding high humidity and direct sunlight,can keep one year in room temperature & humidity.
Logistics
Use wrapping film, corrugated paper to wrap the product, and then use packing rope to secure the card.
Express
Use wrap film and foam wrap, then use corrugated paper to wrap the edge products.

Product Details

Product Overview
Orange peel pattern tin foil adhesive material is a composite material that combines metal tin foil with a high-strength adhesive layer. Its surface is designed with a unique checkered embossing process, featuring both excellent physical properties and practical functions. The products are widely used in fields such as electronic shielding, building waterproofing, industrial sealing, and heat insulation protection, and are renowned for their high adhesion, weather resistance, and electromagnetic shielding properties.

Product features

  • Special checkered pattern design

The surface is embossed with a square grid texture to enhance the material's tensile strength and wear resistance, preventing deformation or tearing during use.

The texture enhances the breathability of the adhesive surface, reduces the residue of air bubbles, and ensures a smoother bond.

  • High-quality tin foil substrate

High-purity aluminum-tin foil layer, with excellent electromagnetic wave shielding performance (up to XX dB or more), is suitable for signal isolation in electronic devices.

High-temperature resistant (-40℃ to 150℃), anti-corrosion, anti-oxidation, and suitable for complex environments.

  • Strong adhesive layer

Coated with acrylic or rubber-based adhesives on the back, it has strong initial adhesion and excellent holding power, and can firmly adhere to various substrates such as metal, plastic and glass.

Some models support removable or solvent-resistant adhesives to meet the needs of different scenarios.

  • Versatility

Waterproof and moisture-proof, heat insulation and reflection (solar reflectivity ≥XX%), sound insulation and noise reduction.

Customized single-sided or double-sided adhesive is available, and it supports processing such as slitting and punching.

Decorative Film Adhesive Material

Technical parameters

  • Project parameter values/performance descriptions
  • Base material thickness: 0.05mm to 0.2mm (customizable)
  • Adhesive type: Pressure-sensitive adhesive/high-temperature resistant adhesive
  • Peel strength ≥XX N/cm (measured data)
  • Temperature resistance range: -40℃ to 150℃
  • Resistance value ≤XX Ω/sq (conductive model)
  • Color: Silver/matte (customizable)

Application field
Electronic and electrical appliances: PCB board shielding, cable wrapping, electronic component isolation.

Building decoration: pipe sealing, roof waterproofing, floor heating reflective layer.

Automotive industry: Wiring harness shielding, engine compartment insulation.

Home DIY: Gap repair, decorative bonding.

Instructions for Use
Clean the surface to be pasted to ensure there is no oil stain or dust.

Cut to the required size, remove the release film and press it to fit.

After construction, apply force by rolling to expel air and enhance the bonding effect.

Packaging specifications
Standard width: 10mm to 1200mm (supports slitting).

Roll length: 10m/ roll, 50m/ roll (customizable).

Quality certification
Passed ISO 9001, RoHS, UL and other certifications (supplemented according to actual qualifications).

Product FAQ

Engraving film is a material that, after being cut by a computer engraving machine, can transfer patterns or characters onto surfaces of the same kind.
Wrap Film is a kind of thin film material used to change the color and texture of the surface of objects. It mainly achieves the appearance color change and decoration of objects such as cars, furniture, electronic products, and architectural glass through the method of pasting and covering. It features convenient construction, rich colors and protection of the base material, and has become a popular personalized modification and decoration material in recent years.
Furniture adhesive materials refer to a type of adhesive products used in the manufacturing, assembly, maintenance or decoration of furniture to achieve the connection, fixation or strengthening of materials. They combine components made of different materials such as wood, metal, plastic, glass and leather through adhesive force, and are one of the key auxiliary materials in furniture production
Glass decorative adhesive materials are a type of composite adhesive materials specifically designed for the decoration, protection or functionalization of glass surfaces. They firmly bond the decorative layer (such as patterns, textures, functional coatings, etc.) to the glass substrate through an adhesive layer, featuring both aesthetic appeal, practicality and ease of construction. It is widely applied in scenarios such as building curtain walls, interior glass partitions, furniture glass, decorative paintings, and glass panels of electronic products
Deerskin flannel adhesive material is a composite functional material that combines the texture of deerskin flannel fabric with an adhesive layer. It features a soft touch, decorative and practical adhesive functions, and is often used in home decoration, gift packaging, electronic protection, handicrafts and other fields
Erasable whiteboard adhesive material is a special functional material used for making or repairing erasable whiteboards (such as office whiteboards and teaching blackboards). Its core features are rewritable property and adhesive fixation ability. It is often used to stick whiteboard panels, repair damaged areas or create temporary writing surfaces.

If you have any questions about our head Stickers material products, please feel free to contact us.
