Stickers Key Attributes
Goods Name
Matte Black Anti Static Polyimide Sticker Matertial
Surface Substrate
Gram Weight
ISO536 67±3 g/m2
Surface Treatment
20 um Nano Transfer Coating
Stickers Adhesive
Dry Coating Weight(g/m²)
ISO536 50±5 gsm
Release Paper
Material Name
Press Finish White Glasin
Gram Weight
ISO536 80±3 g/m2
Physical Test Data
180°Release Force
FTM3 ≤150 g/25mm
180°Peeling Force On Steel Plate
FTM1 ≥5 N/25mm
20 min 90° Peel Viscosity
FTM 2 6 N/25mm
24 hours 90° Peel viscosity
FTM 2 8 N/25m
Application Temperature
-40 ～+ 300℃
Minimum sticking Temperature
10℃
Maximum Sticking Temperature
+40℃
Release Force(g/in)
FTM3 20-30g
Initial Tack
ASTM D3759 ≥3# ,Steel Ball#
Holding Power
FTM8 ＞24h Hour
Shelf Life
It can be stored for one year at a temperature of 23±2℃ and relative humidity of 50±5%
Package Size
Dimensions Standard Width
Valid Width：1070mm，Slitting Minimum Width：25mm
Dimensions Standard Length
500M 1000M
Core Size
Diameter 75mm* Width 1070mm
About Stickers Goods Packing
Logistics
Use wrapping film, corrugated paper to wrap the product, and then use packing rope to secure the card.
Express
Use wrap film and foam wrap, then use corrugated paper to wrap the edge products.
Storage
Keep indoor,airiness,avoiding high humidity and direct sunlight,can keep one year in room temperature & humidity.
Other Attributes
Initial Viscosity (st,st):
FTM 9 8 N/25mm
Short-time High temperature Resistance
At 300 ºC (572 ºF) for 90 seconds
Product Details
Product Description of Anti-static matte black Polyimide Label material
Product Name: Anti-static Matte Black Polyimide Label Material
Anti Static Sticker Product Overview:
Anti-static matte black polyimide label material is a high-performance special label material, specially designed for extreme environments and anti-static requirements. This material is made of high-quality polyimide film as the base material, and its surface has undergone a special matte black treatment. It combines excellent anti-static performance with a low-key matte appearance, and is suitable for high-end marking requirements in fields such as electronics, semiconductors, and aerospace.
Anti Static Sticker Product Features:
- Outstanding high-temperature resistance: It can withstand extreme temperatures ranging from -269℃ to +260℃ for a long time, and short-term temperature resistance can reach over 300℃, making it suitable for high-temperature welding, reflow soldering and other processes.
- Outstanding anti-static performance: The surface resistance value is stably maintained within the range of 10⁶ to 10⁹Ω, effectively preventing the accumulation of static electricity and protecting sensitive electronic components from static damage.
- Matte black appearance and low reflectivity: The low-key matte black surface reduces reflective interference, enhances the aesthetic appeal and concealment of the logo, and is suitable for precision instruments and high-end equipment.
- Chemical stability: Resistant to acids, alkalis, solvents, oils and radiation, maintaining the integrity and clarity of the label even in harsh chemical environments.
- Strong adhesive layer: Made of high-temperature resistant silicone or acrylic adhesive, it bonds firmly without leaving any residue and is suitable for various material surfaces (metal, glass, ceramics, etc.).
- Excellent mechanical properties: tear-resistant, blow-resistant, and not prone to damage in high-speed movement or friction environments.
- Easy processing and adhesion: The back adhesive is made of high-temperature resistant silicone or acrylic adhesive system, with strong adhesion. It can precisely adhere to curved surfaces or complex structures, and there is no residue after removal.
Anti Static Sticker Matertial
Anti Static Sticker Typical Applications:
- Anti-static marking for semiconductor chips, PCB boards and electronic components
- Industrial equipment labels in high-temperature environments (such as engines, thermal pipelines)
- Durability marking for aerospace instruments and precision instruments
- Medical sterilization equipment, high-temperature and high-pressure environmental labels for laboratories
Anti Static Sticker Optional Specifications:
- Thickness: 25μm, 50μm, 75μm (customizable)
- Width: 10mm to 500mm (roll or sheet)
- Adhesive type: Permanent/removable silicone, acrylic adhesive
- Surface resistance: 10⁶ - 10⁹Ω
- Temperature resistance range: -40℃ to +260℃ (long-term)
- Customizable printing (screen printing, laser marking, etc.)
Anti Static Sticker Certification and Compliance
Comply with RoHS, REACH and UL certifications (if applicable), and some models have passed the ISO 10993 biocompatibility test (for medical use).
Anti Static Sticker Applicable Scenarios:
It requires a harsh industrial environment that combines anti-static properties, high-temperature resistance, chemical corrosion resistance and long-term durability.
Why Choose Our Anti Static Sticker Products?
High reliability: Strict quality control, in compliance with RoHS and industry anti-static standards.
Customized service: Supports flexible adjustment of size, adhesive system and resistance value.
Quick response: We offer technical consultation and sample support to help your project progress efficiently.
Suitable for harsh environments that pursue stability and safety - anti-static matte black polyimide stickers, safeguarding your precision equipment
Note: Customer customization of size, color and functional coatings (such as tackifying layer, anti-scratch layer, etc.) is supported.
