Stickers Material Product
Thermal Eggshell Sticker Material

Thermal Eggshell Sticker Material

Thermal eggshell paper self-adhesive material is a special label material specially designed for high security anti-counterfeiting, anti-opening and anti-transfer requirements. It combines the convenience of color development of thermosensitive coatings with the physical property of the substrate itself being "easily torn and broken", and is combined with strong adhesive self-adhesive to form a label solution that is difficult to imitate and reuse. Once pasted and attempted to be completely peeled off, the label will break by itself, effectively preventing the product from being illegally opened, the label from being transferred or reused. It is an ideal choice for ensuring product safety, maintaining brand reputation and tracking responsibility.

Stickers Key Attributes

Goods Name
Thermal Eggshell Sticker Material

Surface Substrate

Material Name
Eggshell Paper
Color
Holographic
Thickness
ISO534 50±3 μm
Gram Weight
ISO536 70±3 g/m2
Longitudinal Tensile Strength
≥0 N/2.5CM
Transverse Tensile Strength
≥0 N/2.5CM
Surface Treatment
15 um Nano Transfer Coating

Stickers Adhesive

Adhesive Type
Acrylic
Dry Coating Weight(g/m²)
ISO536 60±5 gsm
Thickness
ISO534 25±5 μm

Release Paper

Material Name
Press Finish White Glasin
Release Force(g/in)
FTM3 20-30g
Color
White
Gram Weight
ISO536 170±3 g/m2
Thickness
ISO534 160±5 μm

Physical Test Data

Initial Tack
ASTM D3759 ≥3# ,Steel Ball#
Holding Power
FTM8 >24h Hour
Breaking Strength
5.0 Kg/c㎡
180°Peeling Force On Steel Plate
FTM1 ≥3 N/25mm
180°Release Force
FTM3 ≤150 g/25mm
Shelf Life
It can be stored for one year at a temperature of 23±2 C and relative humidity of 50±5%.
Maximum Sticking Temperature
+40℃
Minimum Sticking Temperature
-10℃
Application Temperature
-10 ~+ 80℃

Package Size

Dimensions Standard Width
Valid Width:1070mm,Slitting Minimum Width:25mm
Dimensions Standard Length
500M
Core Size
Diameter 75mm* Width 1070mm
Joint
500M ≤1

About Stickers Goods Packing

Storage Temperature
-10℃-40℃
Storage
Keep indoor,airiness,avoiding high humidity and direct sunlight,can keep one year in room temperature & humidity.
Logistics
Use wrapping film, corrugated paper to wrap the product, and then use packing rope to secure the card.
Express
Use wrap film and foam wrap, then use corrugated paper to wrap the edge products.

Other Attributes

Color
White
Elongation
2%-4%
Tensile Strength
9.0 Kg/15mm

Product Details

Product Name: Thermal Eggshell Paper Sticker Material

Product Overview:

Thermal eggshell paper self-adhesive material is a special label material specially designed for high security anti-counterfeiting, anti-opening and anti-transfer requirements. It combines the convenience of color development of thermosensitive coatings with the physical property of the substrate itself being "easily torn and broken", and is combined with strong adhesive self-adhesive to form a label solution that is difficult to imitate and reuse. Once pasted and attempted to be completely peeled off, the label will break by itself, effectively preventing the product from being illegally opened, the label from being transferred or reused. It is an ideal choice for ensuring product safety, maintaining brand reputation and tracking responsibility.

Core Features Advantages:

  • Outstanding anti-transfer and anti-unsealing performance (core value) :

"Fragile" feature: Made of a special formula of eggshell paper base material, it is extremely fragile in texture.

Tearing and breaking: After pasting, any attempt to tear off or transfer the label completely will cause it to instantly break into small, irregular pieces that cannot be restored. This provides a one-time seal protection for the product, clearly indicating whether the product has been illegally opened or tampered with.

  • Convenient thermal color rendering technology:

No carbon ribbons required, fast printing: With a high-quality thermal coating on the surface, information (text, barcodes, patterns, etc.) can be directly printed through thermal printers (such as barcode printers, receipt printers), without the need for ink cartridges or carbon ribbons. The operation is simple, the printing speed is fast, and the cost-effectiveness is high.

Clear development: The heat-sensitive coating is highly responsive, ensuring clear printed content with high contrast, and guaranteeing the readability and scannability of the information.

  • Strong adhesion and permanent bonding:

Strong initial adhesion and permanent adhesion: Coated with high-performance permanent acrylic adhesive, it has excellent initial adhesion and final adhesion to various common surfaces (such as plastic, glass, metal, paper, etc.).

"Anti-tear" assistance: The combination of strong adhesive water and fragile substrate further ensures that the label will break first when attempted to be peeled off, rather than detach completely from the adhered object.

  • Anti-counterfeiting and security Assurance

Physical anti-counterfeiting: The fragile nature itself is an intuitive and effective physical anti-counterfeiting measure, and it is difficult to imitate its breaking effect through conventional means.

Warning effect: The fragile nature of the label forms a psychological deterrent to potential tampers.

Responsibility traceability: Clear damage marks provide irrefutable evidence as to whether the product has been opened or replaced without authorization, facilitating responsibility traceability and quality assurance management.

VOID Sticker Paper Category

Typical Application Scenarios:

  • Anti-unsealing of electronic products: sealing labels and warranty labels for products such as mobile phones, computers, tablets, game consoles, and household appliances.
  • Anti-counterfeiting and anti-transfer for high-end products: anti-counterfeiting seals and anti-diversion labels for alcoholic beverages, cosmetics, health products, luxury goods, collectibles, etc.
  • Software and games: Sealing labels for software CDS and game cartridges.
  • Instrument and meter calibration seal: Ensure that the equipment has not been modified without authorization during transportation or after use.
  • Important document/package seals: Security seals for confidential document bags, express packages, evidence bags, etc.
  • Warranty and after-sales service: Clearly indicate whether the product is entitled to warranty benefits (the label becomes invalid if damaged).
  • Membership cards and tickets: One-time use vouchers to prevent reuse.

Technical Parameters (example, adjustable according to actual specifications) :

  • Base material: Special eggshell paper (Common weight range: 60-100gsm, such as 70/80 GSM)
  • Surface material: High-quality heat-sensitive coating (heat-sensitive layer)
  • Glue: Permanent acrylic pressure-sensitive adhesive (Strong adhesive type)
  • Base paper: White glassine release paper (weight range: 60-90 GSM, commonly such as 70/80 GSM)
  • Temperature resistance range: The recommended environment for label use is -10°C to +50° C. (The temperature resistance for thermal printed content is typically -20°C to +60° C. Avoid contact with heat sources, solvents, and plasticizers.)
  • Printing method: Thermal Direct Printing
  • Standard core/size: Customizable according to customer requirements (such as 1-inch / 3-inch core, width from 20mm to 100mm+, length, etc.).

Reason for Selection:

  • High-efficiency anti-counterfeiting and anti-tampering: Provide intuitive and reliable physical anti-tampering protection.
  • Convenient and economical printing: Thermal printing saves time and effort, reducing operating costs.
  • Wide application: Suitable for various scenarios that require one-time security seals.
  • Enhance brand trust: Protect consumers' rights and interests, and strengthen the brand's safety image.

Declaration:

This heat-sensitive eggshell paper material is specially designed to provide safety guarantees. Its "fragile" feature depends on proper storage (avoiding high temperature and humidity), operation (avoiding excessive bending), and pasting (ensuring the pasting surface is clean and dry). Once pasted, any attempt to peel it off is bound to cause the label to break.
