Aluminum Foil High-Temperature Tape is a composite adhesive material specially designed for high-temperature environments. It is made by combining high-quality aluminum foil substrate with high-temperature resistant pressure-sensitive adhesive. It boasts excellent temperature resistance, heat insulation, electromagnetic shielding, and sealing properties, and is widely used in high-temperature fixation, insulation protection, or sealing scenarios in fields such as electronics, automobiles, aerospace, and industrial manufacturing.

Stickers Key Attributes

Goods Name
Aluminum Foil Heat Resistant Tape Materal

Surface Substrate

Material Name
Aluminum Foil
Gram Weight
ISO536 18±3 g/m2
Thickness
ISO534 25±3 μm
Color
Silver-white

Stickers Adhesive

Adhesive Type
Acrylic
Dry Coating Weight(g/m²)
ISO536 50±5 gsm
Thickness
ISO534 20±5 μm

Physical Test Data

180°Release Force
FTM3 ≤150 g/25mm
180°Peeling Force On Steel Plate
FTM1 ≥5 N/25mm
20 min 90° Peel Viscosity
FTM 2 6 N/25mm
24 hours 90° Peel viscosity
FTM 2 8 N/25m
Application Temperature
-40 ~+ 300℃
Minimum sticking Temperature
10℃
Maximum Sticking Temperature
+40℃
Release Force(g/in)
FTM3 20-30g
Initial Tack
ASTM D3759 ≥3# ,Steel Ball#
Holding Power
FTM8 >24h Hour
Shelf Life
It can be stored for one year at a temperature of 23±2℃ and relative humidity of 50±5%

Package Size

Dimensions Standard Width
Valid Width:1070mm,Slitting Minimum Width:10mm
Dimensions Standard Length
500M 1000M
Core Size
Diameter 75mm* Width 1070mm
Joint
1000 ≤1

About Stickers Goods Packing

Logistics
Use wrapping film, corrugated paper to wrap the product, and then use packing rope to secure the card.
Express
Use wrap film and foam wrap, then use corrugated paper to wrap the edge products.
Storage
Keep indoor,airiness,avoiding high humidity and direct sunlight,can keep one year in room temperature & humidity.

Product Details

Heat Resistant Tape Product Overview
Aluminum Foil High-Temperature Tape is a composite adhesive material specially designed for high-temperature environments. It is made by combining high-quality aluminum foil substrate with high-temperature resistant pressure-sensitive adhesive. It boasts excellent temperature resistance, heat insulation, electromagnetic shielding, and sealing properties, and is widely used in high-temperature fixation, insulation protection, or sealing scenarios in fields such as electronics, automobiles, aerospace, and industrial manufacturing.

Heat Resistant Tape Core Feature

  • Outstanding high-temperature resistance performance

Long-term operating temperature range: -40℃ to +260℃ (up to 300℃ for short periods), does not peel off or crack under high temperatures.
Both the substrate and the adhesive layer have passed the high-temperature stability test, with no residual adhesive and no deformation.

  • High-efficiency heat insulation and reflection

The aluminum foil layer has an extremely high thermal reflectivity (≥ 95%), which can effectively reflect radiant heat, reduce heat conduction, and enhance energy efficiency.

  • High stickiness and durability

High initial adhesion force, capable of closely adhering to surfaces of various materials such as metals, glass, and ceramics, with peel strength ≥ 8N/cm².
Resistant to aging and acid-base corrosion, with an outdoor service life of over 5 years.

  • Multifunctional additional features

Electromagnetic shielding (suitable for anti-interference of electronic devices)
Waterproof and moisture-proof (The adhesive layer is dense, preventing water vapor from penetrating);
Flame retardant grade UL94 V-0, safe and reliable.

  • Safety and Environmental Protection

Compliant with environmental protection standards such as RoHS, it does not release toxic substances and does not produce harmful gases at high temperatures.

Adhesive Tape Product Series


Heat Resistant Tape Typical Application Scenarios:
Electronics and electrical appliances: Thermal insulation packaging for lithium battery packs, high-temperature protection for circuit boards, and fixation of heat-generating components.
Industrial manufacturing: Fixing of pipe insulation layers, sealing of ovens/broilers, filling of gaps in high-temperature equipment.
Automotive industry: Exhaust pipe insulation, wiring bundle bundling, engine compartment protection.
Construction field: Sealing of HVAC system joints, protection of solar panel back sheets.


Heat Resistant Tape Technical Specifications
Thickness: 0.05mm - 0.15mm (customizable)
Adhesive layer: Acrylic/Organic Silicon Pressure Sensitive Adhesive
Width: 10mm - 1000mm (cuttable)
Color: Silver (standard), Custom color
Certifications: RoHS, REACH, UL certification


Heat Resistant Tape Reasons for Selection
Flexible customization: Supports customization of different thicknesses, widths, and adhesive types (such as silicone compounds with higher heat resistance).
High cost-effectiveness: Compared to imported brands, the cost is reduced by 30% under the same performance.
Professional support: Offer technical selection guidance and sample testing services.
