Stickers Material Product
Mylar Heat Resistant Tape Materal
Mylar Heat Resistant Tape Materal
Mylar Heat Resistant Tape Materal
Mylar Heat Resistant Tape Materal

Mylar Heat Resistant Tape Materal

Aluminum Foil High-Temperature Tape is a composite adhesive material specially designed for high-temperature environments. It is made by combining high-quality aluminum foil substrate with high-temperature resistant pressure-sensitive adhesive. It boasts excellent temperature resistance, heat insulation, electromagnetic shielding, and sealing properties, and is widely used in high-temperature fixation, insulation protection, or sealing scenarios in fields such as electronics, automobiles, aerospace, and industrial manufacturing.

Stickers Key Attributes

Goods Name
Mylar Heat Resistant Tape Materal

Surface Substrate

Material Name
Mylar
Gram Weight
ISO536 18±3 g/m2
Thickness
ISO534 25±3 μm
Color
White

Stickers Adhesive

Adhesive Type
Acrylic
Dry Coating Weight(g/m²)
ISO536 50±5 gsm
Thickness
ISO534 20±5 μm

Physical Test Data

180°Release Force
FTM3 ≤150 g/25mm
180°Peeling Force On Steel Plate
FTM1 ≥5 N/25mm
20 min 90° Peel Viscosity
FTM 2 6 N/25mm
24 hours 90° Peel viscosity
FTM 2 8 N/25m
Application Temperature
-40 ~+ 300℃
Minimum sticking Temperature
10℃
Maximum Sticking Temperature
+40℃
Release Force(g/in)
FTM3 20-30g
Initial Tack
ASTM D3759 ≥3# ,Steel Ball#
Holding Power
FTM8 >24h Hour
Shelf Life
It can be stored for one year at a temperature of 23±2℃ and relative humidity of 50±5%

Package Size

Dimensions Standard Width
Valid Width:1070mm,Slitting Minimum Width:10mm
Dimensions Standard Length
500M 1000M
Core Size
Diameter 75mm* Width 1070mm
Joint
1000 ≤1

About Stickers Goods Packing

Logistics
Use wrapping film, corrugated paper to wrap the product, and then use packing rope to secure the card.
Express
Use wrap film and foam wrap, then use corrugated paper to wrap the edge products.
Storage
Keep indoor,airiness,avoiding high humidity and direct sunlight,can keep one year in room temperature & humidity.

Product Details

Introduction to the Mapei Thermal Glue Tape Products
Product Name: Movi Tape High Temperature Adhesive Tape
Product Model: Customized according to customer requirements
Application Scope: Used for high-temperature shielding and protection in industries such as electronics, automobiles, construction, painting, and packaging.


Heat Resistant Tape Product Overview
Warp Tape High Temperature Adhesive is a special type of adhesive tape made from warp paper as the base material and coated with high-temperature resistant pressure-sensitive adhesive. It features excellent high-temperature resistance, easy peeling and removal, and no residue after application. It is widely used in scenarios such as shielding protection, fixation, and marking in high-temperature environments.


Heat Resistant Tape Product features

  • Excellent high-temperature resistance performance

Acceptable temperature range: -20℃ ~ 200℃ (up to 230℃ for short periods), suitable for high-temperature processes such as baking, painting, and electronic component welding.

  • Moderate stickiness, no residue glue after removal

Using special pressure-sensitive adhesive, the adhesion is stable. After removal, no residue adhesive remains and the surface being adhered is not damaged.

  • Flexible and easy to tear, with convenient operation.

The base material of the Mapei tape is soft and can be easily torn off. It can be easily applied to curved surfaces or complex shapes, and the construction efficiency is high.

  • Anti-solvent, anti-permeation

The surface of the tape is resistant to common solvents (such as paint and ink), preventing contamination caused by penetration.

  • Multiple colors are available for selection.

Offer colors such as white, beige, green, etc., which are convenient for classification identification or aesthetic purposes.

Adhesive Tape Product Series

Heat Resistant Tape Technical Specifications

Base Material:High-quality masking paper
Adhesive:Toughened acrylic glue/silicone
Thickness: 0.10mm - 0.25mm (customizable)
Width:5mm - 50mm (customizable)
Temperature Resistance Range: -20℃ - 200℃
Tensile Strength:≥50 N/cm²
Shelf Life:12 months (in a cool and dry environment)


Typical Application Scenarios
Electronic Industry: PCB board welding shielding, electronic component high-temperature fixation.
Automobile manufacturing: Painting masking, high-temperature baking for protection.
Building decoration: Wall surface color coating, installation and protection of glass curtain walls.
Industrial packaging:Bundle or label the components used in high-temperature environments.


Heat Resistant Tape Usage Notes
Before attaching, clean the surface to ensure there is no oil, dirt or dust.
It is recommended to attach it at room temperature and then gradually increase the temperature to achieve the best temperature resistance performance.
Store in a cool and dry place, avoiding direct sunlight.


Heat Resistant Tape Packaging specifications
Standard roll size: Length 10m/20m/50m, Inner diameter 76mm.
Sizes and packaging methods can be customized according to customer requirements.


Choose our Mapei paper heat-seal tape and you will get:
High-quality base material - strong and not prone to breaking.
Environmental certification - compliant with RoHS/REACH standards.
Professional customization service - supports personalized customization of color, size, and glue type.

Product FAQ

Engraving film is a material that, after being cut by a computer engraving machine, can transfer patterns or characters onto surfaces of the same kind.
Wrap Film is a kind of thin film material used to change the color and texture of the surface of objects. It mainly achieves the appearance color change and decoration of objects such as cars, furniture, electronic products, and architectural glass through the method of pasting and covering. It features convenient construction, rich colors and protection of the base material, and has become a popular personalized modification and decoration material in recent years.
Furniture adhesive materials refer to a type of adhesive products used in the manufacturing, assembly, maintenance or decoration of furniture to achieve the connection, fixation or strengthening of materials. They combine components made of different materials such as wood, metal, plastic, glass and leather through adhesive force, and are one of the key auxiliary materials in furniture production
Glass decorative adhesive materials are a type of composite adhesive materials specifically designed for the decoration, protection or functionalization of glass surfaces. They firmly bond the decorative layer (such as patterns, textures, functional coatings, etc.) to the glass substrate through an adhesive layer, featuring both aesthetic appeal, practicality and ease of construction. It is widely applied in scenarios such as building curtain walls, interior glass partitions, furniture glass, decorative paintings, and glass panels of electronic products
Deerskin flannel adhesive material is a composite functional material that combines the texture of deerskin flannel fabric with an adhesive layer. It features a soft touch, decorative and practical adhesive functions, and is often used in home decoration, gift packaging, electronic protection, handicrafts and other fields
Erasable whiteboard adhesive material is a special functional material used for making or repairing erasable whiteboards (such as office whiteboards and teaching blackboards). Its core features are rewritable property and adhesive fixation ability. It is often used to stick whiteboard panels, repair damaged areas or create temporary writing surfaces.

If you have any questions about our head Stickers material products, please feel free to contact us.
